Hentg Power 45kVA 75kVA 112kVA YBM Outdoor High Voltage Substation Substation Room Medium Voltage Substation Compact Transformer
Product Specifications
| Type | Power transformer, distribution transformer, Auto Transformer |
| Frequency | 50Hz, 60Hz |
| Winding Material | Aluminum |
| Application | Power Distribution System |
| Phase | Three |
| Input Voltage | 3kV, 6kV, 10kV, 15kV, 35kV, 69kV, 110kV, 220kV, 400kV, 115kV, 132kV |
| Output Voltage | 5V, 400V, 208V, 200V, 415V, 127V, 11kV, 12V, 24V, 48V, 110V, 220V, 36V, 380V, 440V, 480V, 9V |
| Efficiency | 98% |
| Insulation Class | Class F |
| Operating Temperature | -25°C to 40°C |
| Cooling Method | ONAN |
| Noise Level | less than 60 dB |
| Protection Class | IP23 |
| Rated Power | 1000 kVA |
Product Overview
The YBM Outdoor High Voltage Substation is a fully sealed, fully insulated ground-mounted distribution unit, widely used in residential areas, shopping centers, industrial plants, and public parks. Built to North American standards, it offers high reliability, enhanced safety, and easy installation.
Technical Specifications
High Voltage (HV) Parameters
- Rated Frequency: 50 Hz
- Rated Voltage: 6kV, 10kV, 35kV
- Max Working Voltage: 6.9kV, 11.5kV, 40.5kV
- Industrial Frequency Voltage-resisting Time: 32/36kV, 42/48kV, 95/118kV
- Rated Current: 400A, 630A
Low Voltage (LV) Parameters
- Rated Voltage: 380V, 220V
- Rated Current Of Major Return Circuit: 100-3200A
- Rated short-circuit Current-resisting: 15kA, 30kA, 50kA
- Branch Circuit: 10-800A
Transformer Specifications
- Rated Capacity: 50-2000 kVA
- Short-circuit Impedance: 4%, 6%
- Vector Group: Yyn0, Dyn11
Our Manufacturing Process
Step 1: Consultation & Design
We respond to inquiries within 1 hour and recommend suitable transformers according to your needs. Our professional drawing and technical teams will confirm all design details with you within 7 days after payment, including technical data, weight, and parts list.
Step 2: Production & Quality Control
After finalizing the design, we prepare stock, produce, and conduct rigorous quality inspections before shipment. We provide both QC reports and test reports, ensuring product quality meets international standards including GB 20052-2024, ANSI/IEEE, DOE2016, CSA, and IEC60076.
Step 3: Installation & Support
Our professional team provides installation guidance and on-site support. We offer more than 2 years of warranty service, ensuring long-term reliability of your power distribution system.
Our Manufacturing Capabilities
- 30+ senior engineers offering 24/7 online support with 30-minute response time
- 100,000m² factory with 250 skilled workers and 30+ engineers
- 4 production lines with 10,000+ sets annual production capacity
- 100% OQC testing with 25 detection parameters
- 15 years of power transformer design and production experience
- Compliance with GB 20052-2024, ANSI/IEEE, DOE2016, CSA, IEC60076 standards
Key Advantages
Aesthetic and Durable Appearance
The unit features a clean, modern design with strong environmental adaptability, integrating well with surrounding architecture and landscaping while enhancing urban aesthetics.
Proximity to Medium-Voltage Load Centers
Enables deployment close to load centers, reducing distribution line length, lowering line losses, and improving power quality and supply reliability.
Cost-Effective Operation
Requires no civil infrastructure, reducing initial investment. Long maintenance cycles and easy operation result in lower total cost of ownership throughout the lifecycle.
Environmentally Friendly Design
The modular substation can be relocated and reused based on urban development needs, supporting sustainable development goals.
Frequently Asked Questions
Who are we?
HENTG POWER is a professional designer, manufacturer and installer of power system solutions founded in 2011. Our 100,000 square meter facility specializes in reliable, high-performance solutions for global power systems.
How can we guarantee quality?
We conduct pre-production sampling and final inspections before shipment, providing QC & test reports. We manufacture oil type and dry type distribution transformers up to 500KV 480MVA, GIS, switchgear, and substations, all meeting international standards.
Why choose us?
We offer professional design teams that confirm drawings within 7 days and technical teams with 30+ senior engineers providing 24/7 support with 30-minute response times.
What services can we provide?
We accept OEM orders and negotiate business payment terms to meet your specific requirements.
